Default D-Link Unified Switch Settings 203

D-Link Unified Access System Default

Settings

This chapter identifies the default values for the D-Link Unified Switch, the default D-Link

Access Point settings, and the default AP Profile setting that the switch assigns to the AP after

it is discovered and authenticated (when the AP uses the default profile).

Default D-Link Unified Switch Settings

Table 76 shows the default settings for the D-Link Unified Switch.

Table 76. Switch Defaults

Feature Default

System Information

User Name admin

Password None

Network Information

DHCP Client Disabled

Network Configuration Protocol None

IP Address 10.90.90.90

Subnet Mask 255.0.0.0

802.1Q Enabled

Management VLAN ID 1

Untagged VLAN ID 1

Spanning Tree Protocol Enabled

Default Chapter3
- Table of Contents3
List of Figures9
List of Tables13
About this Document15
- Audience15
- Organization15
- Document Conventions15
- Safety Instructions16
1 Overview of the D-Link Unified Access System21
- D-Link Unified Access System Components21
- D-Link Unified Access System Topology23
- Understanding the User Interfaces25
- Wireless System Features and Standards Support30
2 Planning the D-Link Unified Access System Network33
- System Requirements33
- WLAN Topology Considerations34
- Network Planning to Support Layer 3 Roaming37
- Figure 10. Inter-Subnet Roaming38
3 Installing the Hardware39
- Hardware Overview39
- Installation44
- Connecting the Switch49
4 Installing the D-Link Unified Access System53
- System Deployment Overview53
- Connecting the Switch to the Network55
- Enabling the WLAN Features on the Switch56
- Table 3. Basic Wireless Global Configuration56
- Preparing the Access Points58
- Discovering Access Points and Peer Switches61
- Authenticating and Validating Access Points74
5 Configuring Access Point Settings83
- AP Profiles, Networks, and the Local Database83
- Configuring AAA and RADIUS Settings85
  - Table 7. Global RADIUS Server85
  - Figure 37. MAC Access Control86
- Configuring Wireless Radio Settings87
- Configuring SSID Settings93
- Configuring Valid Access Point Settings106
- Resetting the Access Points109
  - Figure 49. Access Point Reset109
6 Managing and Maintaining D-Link Access Points109
- Managing Radio Frequency Settings110
- Upgrading the Access Point Software116
- Performing Advanced Access Point Management119
7 Monitoring Status and Statistics123
- Monitoring Wireless Global Information123
- Monitoring Peer Switch Status126
  - Figure 58. Wireless Discovery Status126
- Monitoring All Access Points127
- Monitoring Rogue and RF Scan Access Points143
  - Table 39. Access Point Authentication Failure Status143
  - Figure 64. RF Scan144
- Monitoring Associated Client Information145
- Monitoring and Managing Ad Hoc Clients153
8 Configuring Advanced Settings155
- Creating, Configuring, and Managing AP Profiles155
- Configuring Global Settings159
  - Figure 72. Global Configuration159
  - Table 53. General Global Configurations160
- Enabling SNMP Traps161
9 Configuring the Captive Portal167
- Figure 75. Navigating to the Captive Portal Feature167
- Configuring Global Captive Portal Settings168
  - Figure 76. Global Captive Portal Configuration168
  - Table 56. Global Captive Portal Configuration168
- Configuring the Captive Portal169
- Monitoring and Configuring Captive Portal Users174
- Associating Interfaces with the Captive Portal177
  - Figure 82. Global Captive Portal Configuration177
  - Table 63. Global Captive Portal Configuration177
- Viewing the Captive Portal Global Status178
- Viewing the Client Summary183
10 Visualizing the Wireless Network189
- Importing and Configuring a Background Image190
- Figure 93. Sample WLAN Visualization190
- Setting up the Graph Components191
- Understanding the Menu Bar Options196
- Managing the Graph201
- Figure 102. Wireless Component Attributes201
- Table 75. Component Information201
A D-Link Unified Access System Default Settings203
- Default D-Link Unified Switch Settings203
- Table 76. Switch Defaults203
- Default D-Link Access Point Settings204
- Table 77. Default AP Settings204
- Default D-Link Access Point Profile Settings205
- Table 78. AP Profile Default Settings205
- Default Captive Portal Settings206
- Table 79. Default Captive Portal Settings206
B Configuring the External RADIUS Server207
- Configuring RADIUS Settings for Access Points207
- Table 80. RADIUS Attributes for the Access Point207
- Freeradius Server Configuration Example209
- Configuring RADIUS Settings for Wireless Clients211
- Freeradius Example for Wireless Client Configuration212
  - Configuring User-Based Authentication and Dynamic Vlans212
  - Configuring MAC Authentication213
C L3 Roaming Example215
- Configuring the WLAN and Tunnel Interfaces216
- Configuring the L3 Tunnel Network220
- Configuring DHCP Relay and the DHCP Server225
  - Configuring the Relay Agent225
  - Configuring the DHCP Server226
D Understanding Quality of Service229
- Qos and Load Balancing229
- 802.11E and WMM Standards Support229
- Coordinating Traffic Flow230
- Qos Queues and DSCP on Packets230
- EDCF Control of Data Frames and AIFS231
- Random Backoff and Contention Windows232
- Packet Bursting for Better Performance232
- TXOP Interval for Client Stations233
- 802.1P and DSCP Tags233
- Figure 104. Traffic Prioritization234
- Table 84. VLAN Priority Tags234
E Limited Warranty (USA Only)235
- Product Registration239
- Limited Warranty240
Technical Support243
- Assistance Technique246
- Pomoc Techniczna250
- International Offices267
- Registration Card All Countries and Regions Excluding USA268
