174 © 2001- 2008 D-Link Corporation. All Rights Reserved.
D-Link Unified Access System User Manual
Use the buttons at the bottom of the page to perform the following tasks:
• To reset the page to the default values, click Clear.
• To preview the customized page, click Preview.
• To apply the changes to the switch, click Submit.
Monitoring and Configuring Captive Portal Users
You can configure a portal to accommodate guest users and authorized users. Guest users do
not have assigned user names and passwords. Authorized users provide a valid user name and
password that must first be validated against a local database or RADIUS server. Authorized
users can gain network access once the D-Link Unified Switch confirms the user’s credentials.
The Local User Summary page allows you to add authorized users to the local database,
which can contain up to 1024 user entries. You can also delete users from the local database
from the Local User Summary page.
To view and configure CP users in the local database, click Security > Captive Portal >
Local User.
Any users that are already configured are listed on the Local User Summary page.
Figure 80. Captive Portal Local User Summary
Table 60 describes the fields on the Local User Summary page.
Busy Message Enter the text to display when the Captive Portal is processing the
authentication request. This message displays after the user clicks the button
to connect to the network.
No Accept
Message
Enter the text to display when the user did not accept the acceptance use
policy. This message displays after the user clicks the button to connect to the
network.
Welcome Title Enter the title to display to greet the user after he or she successfully connects
to the network.
Welcome Text Enter the optional text to display to further identify the network to be
accessed by the CP user. This message displays under the Welcome Title.
Table 59. CP Web Page Customization
Field Description
