User's Manual
196
Figure 4-95
Step 3 Click the direction arrows to position the left and right limits.
4.4.4 Calling PTZ Functions
After you have configured the PTZ settings, you can call the PTZ functions for monitoring from the
Expanded PTZ Control Panel. See Figure 4-96.
Figure 4-96
4.4.4.1 Calling Presets
Procedure
Step 1 On the expanded PTZ control panel, in the
No.
box, enter the value of the preset that you
want to call.
Step 2 Click to call the preset.
Step 3 Click again to stop calling the preset.
4.4.4.2 Calling Tours
Procedure
Step 1 On the expanded PTZ control panel, in the
No.
box, enter the value of the tour that you
want to call.
Step 2 Click to call the tour.
To Next Page
