User's Manual
352
recommend that you use the default setting.
Step 3 Click
Apply
.
PoE Port Description
Table 4-79
PoE Status Description
Connect to PoE port
When an IPC is connected to the PoE port, the system automatically
assigns the IP address to the IPC according to the set IP segment. The
NVR will try the method of
arp ping
to assign the IP address. If DHCP is
enabled on the NVR, the NVR will use DHCP to assign the IP address.
●
When IP address is successfully set, the system will broadcast
though
Switch
. If there is a response from the IPC, it means the
connection is successful, and the NVR will log in with the IPC. You
can find the corresponding channel being occupied and there is an
PoE icon at the upper-left corner.
●
You can also view PoE status such as channel number and PoE port
number in
Main Menu
>
CAMERA
>
Camera List
>
Added Device
Disconnect PoE port
When an IPC is disconnected form PoE port, you will find the
information of
Failed to find network host
on the
Live View
interface.
PoE connection
mapping
The PoE ports are bound to corresponding channels. When an IPC is
connected to PoE port 1, the corresponding channel is Channel 1.
4.11.17 P2P
Background Information
P2P is a kind of convenient private network penetration technology. You do not need to apply for
dynamic domain name, doing port mapping or deploying transit server. You can add NVR devices
through the below way to achieve the purpose of managing multiple NVR devices at the same time.
●
Scan the QR code, download mobile app, and then register an account. For details, see Mobile
App Operation.
●
Log in to www.gotop2p.com, register an account, and then add device via the serial number. For
details, see Introduction of P2P Operations.
Connect the NVR device to the Internet, otherwise P2P can not run properly.
Procedure
Step 1 Select
Main Menu
>
NETWORK
>
P2P
.
The
P2P
interface is displayed. See Figure 4-236.
