User's Manual
418
Figure 5-3
Step 2 Configure parameters.
Table 5-2
Parameter Description
Device Name This parameter is user defined.
IP Address Enter the IP address of the NVR.
Port
Set the TCP port number of the server. The default value is 37777.
You can view the current TCP port number in
SETTING
>
Network
>
Port
Username/Password Enter the username and password of the NVR.
Step 3 Click
OK
.
Step 4 (Optional) Click to view event occurrence time, name, operation and reason.
5.4.3 Sub Device
Background Information
When you add the first sub device, the default IP is the device IP address that logins on the web.
From
SETTING
>
Cluster Service
>
Sub Device
, you can go to the
Sub Device
interface.
See "5.4.2 Main Device" to add sub device.
After you added main device and sub device, you need to enable cluster function. Otherwise, cluster
function is null. See "5.4.5 Cluster Control" for more information.
5.4.4 Transfer Record
When the main device is in malfunction and the sub device starts to record. The NVR automatically
