User's Manual
203
Icon Function
In 1-channel playback mode, click it to enable/disable display IVS rule
information on the video.
This function is for some series only.
Picture search. For details, see "4.6.4 Picture Search Playback"
4.6.2.2 Search Type
You can search the recorded videos, splice, or snapshots from Disk or external storage device.
●
From R/W Disk: Recorded videos or snapshots playback from HDD of the Device. See Figure 4-
100.
Figure 4-100
●
From I/O Device: Recorded videos playback from external storage device. See Figure 4-101.
Click
Browse
, select the save path of recorded video file that you want to play. Double-click the
video file or click to start playing.
Figure 4-101
4.6.2.3 Clip
Background Information
This function allows you to clip some footages to a new file and then save it to the USB device. See
Figure 4-102. Follow the steps listed below.
●
Clip function is for one-channel/multiple-channel.
●
Max save 1024 files at the same time.
●
This function is not for the file already checked in the file list.
Procedure
Step 1 Select a record first and then click to playback.
Step 2 Select a time at the time bar and then click to start clip.
Step 3 Select a time at the time bar and then click to stop clip.
Step 4 Click , system pops up dialogue box to save the clip file.
To Next Page
