Fujitsu 8FX User Manual

MB95630H Series
190 FUJITSU SEMICONDUCTOR LIMITED MN702-00009-2v0-E
CHAPTER 13 INTERRUPT PIN SELECTION CIRCUIT
13.3 Pins
13.3 Pins
This section describes the pins of the interrupt pin selection circuit.
■ Pins of Interrupt Pin Selection Circuit
The peripheral function pins of the interrupt pin selection circuit are the EC1, INT00, TRG1,
UCK0 and UI0 pins. These input pins (except INT00) are also connected to their respective
peripheral units in parallel and can be used for both functions simultaneously. Table 13.3-1
shows the correspondence between the peripheral functions and peripheral input pins.
Table 13.3-1 Correspondence between Peripheral Functions and Peripheral
Input Pins
Peripheral input pin name Peripheral functions name
EC1 8/16-bit composite timer (event input)
INT00 Interrupt pin selection circuit
TRG1 16-bit PPG timer (trigger input)
UCK0 UART/SIO (clock input/output)
UI0 UART/SIO (data input)
