CHAPTER 19 16-BIT PPG TIMER
19.3 Channel
19.3 Channel
This section describes the channel of the 16-bit PPG timer.
■ Channel of 16-bit PPG Timer
Table 19.3-1 and Table 19.3-2 show the pins and registers on a channel of the 16-bit PPG timer
respectively.
Table 19.3-1 Pins of 16-bit PPG Timer
Pin name Pin function
PPGn 16-bit PPG timer PPGn output
TRGn Trigger n input
Table 19.3-2 Registers of 16-bit PPG Timer
Register
abbreviation
Corresponding register (Name in this manual)
PDCRHn 16-bit PPG downcounter register (upper) ch. n
PDCRLn 16-bit PPG downcounter register (lower) ch. n
PCSRHn 16-bit PPG cycle setting buffer register (upper) ch. n
PCSRLn 16-bit PPG cycle setting buffer register (lower) ch. n
PDUTHn 16-bit PPG duty setting buffer register (upper) ch. n
PDUTLn 16-bit PPG duty setting buffer register (lower) ch. n
PCNTHn 16-bit PPG status control register (upper) ch. n
PCNTLn 16-bit PPG status control register (lower) ch. n
