MB95630H Series

200 FUJITSU SEMICONDUCTOR LIMITED MN702-00009-2v0-E

CHAPTER 14 LIN-UART

14.2 Configuration

LIN-UART is made up of the following blocks.

• Reload counter

• Receive control circuit

• Receive shift register

• LIN-UART receive data register (RDR)

• Transmit control circuit

• Transmit shift register

• LIN-UART transmit data register (TDR)

• Error detection circuit

• Oversampling circuit

• Interrupt generation circuit

• LIN synch break/synch field detection circuit

• Bus idle detection circuit

• LIN-UART serial control register (SCR)

• LIN-UART serial mode register (SMR)

• LIN-UART serial status register (SSR)

• LIN-UART extended status control register (ESCR)

• LIN-UART extended communication control register (ECCR)
