MB95630H Series
598 FUJITSU SEMICONDUCTOR LIMITED MN702-00009-2v0-E
CHAPTER 28 COMPARATOR
28.4 Interrupt
28.4 Interrupt
The voltage generator generates an interrupt called output edge detection
interrupt. An interrupt request number and an interrupt vector are assigned to
the interrupt.
■ Output Edge Detection Interrupt
Table 28.4-1 shows details of the output edge detection interrupt.
Note:
In stop mode, watch mode or time-base timer mode, the edge detection circuit stops
operating, and the output edge detection interrupt flag bit (IF) in the comparator control
register (CMR0C) will not be updated even if the comparator has been turned on.
Table 28.4-1 Details of Output Edge Detection Interrupt
Item Details
Interrupt generating condition An output rising edge or output falling edge occurs.
Interrupt flag CMR0C:IF
Interrupt enable bit CMR0C:IE
