CHAPTER 18 8/16-BIT PPG
18.6 Operations and Setting Procedure Example
18.6.3 16-bit PPG Mode
In this mode, the 8/16-bit PPG can operate as a 16-bit PPG when PPG timer n1
and PPG timer n0 are assigned to the upper and lower bits respectively.
■ Setting 16-bit PPG Mode
The 8/16-bit PPG requires the register settings shown in Figure 18.6-5 to operate in 16-bit PPG
mode.
Figure 18.6-5 Setting 16-bit PPG Mode
■ Operation of 16-bit PPG Mode
• This mode is selected by setting the operation mode select bits (MD[1:0]) in the PPG timer
n0 control register (PCn0) to "0b10" or "0b11".
• When the PPG timer n0 (ch. n) downcounter operation enable bit (PEN00) is set to "1" in
16-bit PPG mode, the 8-bit downcounters (PPG timer n0) and 8-bit downcounter (PPG
timer n1) load the values in the 8/16-bit PPG timer n1/n0 cycle setup buffer registers
(PPSn1 for PPG timer n1 and PPSn0 for PPG timer n0) and start down-count operation.
When the count value reaches "1", the values in the cycle setup register are reloaded and the
counters repeat the counting.
• When the values of the downcounters match the values in the 8/16-bit PPG timer duty setup
buffer registers (both the value in PDSn1 for PPG timer n1 and the value in PDSn0 for PPG
timer n0), the PPGn0 pin is set to "H" synchronizing with the count clock. After "H" which
bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit0
PCn1 - - PIE1 PUF1 POEN1 CKS12 CKS11 CKS10
PCn0 MD1 MD0 PIE0 PUF0 POEN0 CKS02 CKS01 CKS00
00/1
PPSn1 PH7 PH6 PH5 PH4 PH3 PH2 PH1 PH0
PPSn0 PL7 PL6 PL5 PL4 PL3 PL2 PL1 PL0
PDSn1 DH7 DH6 DH5 DH4 DH3 DH2 DH1 DH0
PDSn0 DL7 DL6 DL5 DL4 DL3 DL2 DL1 DL0
PPGS - - PEN21 PEN20 PEN11 PEN10 PEN01 PEN00
******×
REVC - - REV21 REV20 REV11 REV10 REV01 REV00
******×
: Used bit
0 : Set to "0"
1 : Set to "1"
× : Setting nullified
* : The bit status changes depending on the number of channels implemented.
Set PPG output cycle (Upper 8 bits) for PPG timer n1
Set PPG output cycle (Lower 8 bits) for PPG timer n0
Set PPG output duty (Upper 8 bits) for PPG timer n1
Set PPG output duty (Lower 8 bits) for PPG timer n0
