Fujitsu 8FX User Manual

MB95630H Series
MN702-00009-2v0-E FUJITSU SEMICONDUCTOR LIMITED 589
CHAPTER 27 NON-VOLATILE REGISTER (NVR) INTERFACE
27.4 Notes on Main CR Clock Trimming
27.4 Notes on Main CR Clock Trimming
This section provides notes on main CR clock trimming.
After a hardware reset, the 10-bit main CR clock trimming value and the 5-bit temperature
dependent adjustment value will be loaded from the NVR Flash area to registers in the NVR
I/O area.
Table 27.4-1 shows the step size of main CR clock trimming.
Table 27.4-1 Step Size of Main CR Clock Trimming
Function
Coarse trimming value
CRTH[4:0]
Fine trimming value
CRTL[4:0]
To achieve the minimum frequency 0b11111 0b11111
To achieve the maximum frequency 0b00000 0b00000
Step Size 220 kHz to 300 kHz 14 kHz to 20 kHz
