MB95630H Series

MN702-00009-2v0-E FUJITSU SEMICONDUCTOR LIMITED 309

CHAPTER 18 8/16-BIT PPG

18.3 Channel

This section describes the channel of the 8/16-bit PPG.

■ Channel of 8/16-bit PPG

The 8/16-bit PPG consists of 8-bit PPG timer n0 and 8-bit PPG timer n1. They can be used

respectively as two 8-bit PPGs or as a single 16-bit PPG.

Table 18.3-1 shows the pins and Table 18.3-2 the registers.

Table 18.3-1 Pins of 8/16-bit PPG

Pin name Pin function

PPGn0 PPG timer n0 (8-bit PPG (n0), 16-bit PPG)

PPGn1 PPG timer n1 (8-bit PPG (n1), 8-bit prescaler)

Table 18.3-2 Registers of 8/16-bit PPG

abbreviation

Corresponding register (Name in this manual)

PCn1 8/16-bit PPG timer n1 control register

PCn0 8/16-bit PPG timer n0 control register

PPSn1 8/16-bit PPG timer n1 cycle setup buffer register

PPSn0 8/16-bit PPG timer n0 cycle setup buffer register

PDSn1 8/16-bit PPG timer n1 duty setup buffer register

PDSn0 8/16-bit PPG timer n0 duty setup buffer register

PPGS 8/16-bit PPG start register

REVC 8/16-bit PPG output inversion register
