3 USING THE HMI PANEL
Using the HMI, you can:
● Display and modif
y settings
● View the digital I/O signal status
● Display measurements
● Display fault records
● Reset fault and alarm indications
The keypad provides full access to the device functionality using a range of menu options. The information is
displayed on the LCD.
Keys Description Function
Up and down cursor keys
To change the menu level or change between settings in a
par
ticular column, or changing values within a cell
Left and right cursor keys
To change default display, change between column
headings, or changing v
alues within a cell
ENTER key For changing and executing settings
Hotkeys
For executing commands and settings for which shortcuts
hav
e been defined
Cancel key To return to column header from any menu cell
Read key To read alarm messages
Function keys (not all models) For executing user programmable functions
P54A/B/C/E Chapter 5 - Configuration
P54xMED-TM-EN-1 77
