Module 57
Reset CB Lockout
Reset Lockout
Res LO by CB IS
CB1CRLO
Res LO by UI
AR Disabled
Reset CB LO
Res LO by NoAR
Num CBs
Res LO by ExtDDB
A/R Lockout
Res LO by Tdelay
LO Reset Time
RESCB1LO
Module 59
System Checks Voltage
Monitor
System Checks
Inhibit LB1
Inhibit DB 1
Inhibit LL
Inhibit DL
MCB/VTS
MCB/VTS CB1 CS
Live Line
Dead line
Dead Bus
Live Bus
Module 60
Check Sync Signals
System Checks
MCB/VTS
MCB/VTS CB1 CS
VTS Fast Block
F out of Range
CS1 Enabled
CS2 Enabled
CS1 Status
CS2 Status
CS1 SlipF>
Check Sync 1 OK
Check Sync 2 OK
CS1 SlipF<
CS2 SlipF>
CS VBus>
CS2 SlipF<
CS VLine>
CS VLine<
CS VBus<
CS1 VL>VB
CS1 VL<VB
CS1 AngHigh+
CS1 FL>FB
CS1 FL<FB
CS1 AngHigh-
CS2 AngHigh+
CS2 FL>FB
CS2 FL<FB
CS2 AngHigh-
CS AngRotACW
CS AngRotCW
CS2 VL>VB
CS2 VL<VB
SysChks Inactive
Module 62
Pole Discrepancy
A/R Lockout
Lockout Alarm
Pole Discrepancy
AR 1pole in prog
CB Open A ph
CB Open B ph
CB Open C ph
Pole Discrepancy
Trip Inputs A
Trip Inputs B
Trip Inputs C
Tripping Mode
AR Force 3 pole
Force 3Pole Trip
Trip Inputs 3Ph
Pole Dead A
Pole Dead B
Pole Dead C
Module 63
CB Trip Conversion
Trip OutputA
Trip OutputB
Trip OutputC
Trip 3ph
Any Trip
2/3 Ph Fault
3 Ph Fault
V03392-5
VAN
VBN
VCN
VAB
VBC
VCA
VBus
VAN
VBN
VCN
VAB
VBC
VCA
VBus
Figure 56: Autoreclose System Map - part 5
Chapter 7 - Autoreclose P54A/B/C/E
138 P54xMED-TM-EN-1
