4.2 AUTORECLOSE INTERNAL SIGNALS
The following table lists all the internal signals used in the CB control and Autoreclose logic system:
Signal Name Source Module Destination Module Description
3PDTCOMP 3-phase AR Dead Time (25) 3-phase AR Dead Time (25) Three phase dead time complete
AR DISABLED AR Enabled (5)
Force 3-phase Trip (10)
1-pole / 3-pole Trip (13)
AR Reset Successful (37)
Reset CB Lockout (57)
Overall Autoreclosing disabled
BAR CB1 Autoreclose Lockout (55) AR OK (8) Block Autoreclose
CB1 3PDTCOMP 3-phase AR Dead Time (25)
CB Autoclose (32)
Prepare Reclaim Initiation (34)
CB Healthy and System Check
Timers (39)
Three-pole Autoreclose dead time is complete
CB1 AROK AR OK (8) AR In Progress (16) CB is OK for Autoreclose
CB1 ARSUCC Successful AR Signals (36)
AR In Progress (16)
AR Reset Successful (37)
Autoreclose successful
CB1 LARIP AR In Progress (16)
1-phase AR Cycle Selection (19)
3-phase AR Cycle Selection (21)
Reclaim Time (35)
CB Autoreclose in progress
CB1 Op1P CB Open (3)
Dead Time Start Enable (22)
CB Autoclose (32)
Successful AR Signals (36)
CB is open on 1 phase
CB1 Op2/3P CB Open (3)
AR In Progress (16)
3-phase AR Cy
cle Selection (21)
1-phase AR Dead Time (24)
Successful AR Signals (36)
CB is open on 2 or 3 phases
CB1 OpAny CB Open (3)
AR In Progress (16)
AR Reset Successful (37)
Autoreclose Lockout (55)
CB is open on 1, 2 or 3 phases
CB1 SPOK Force 3-phase Trip (10) CB is OK for single-phase Autoreclose
CB1CRLO CB In Service (4) Reset CB Lockout (57) Reset CB lockout
CB1L3PAR
3-phase AR Cycle Selection
(21)
1-phase AR Cycle Selection (19)
3-phase AR Dead Time (25)
CB Autoclose (32)
Three-phase Autoreclose is active
CB1L3PAROK AR Modes Enable (9)
AR In Progress (16)
3-phase AR Cycle Selection (21)
Autoreclose Lockout (55)
CB is OK to perform three-phase Autoreclose
CB1LSPAR
1-phase AR Cycle Selection
(19)
1-phase AR Dead Time (24)
CB Healthy and S
ystem Check
Timers (39)
Single-phase Autoreclose is in progress
CB1LSPAROK AR Modes Enable (9)
Force 3-phase Trip (10)
1-phase AR Cycle Selection (19)
3-phase AR Cycle Selection (21)
Autoreclose Lockout (55)
CB is OK to perform single-phase Autoreclose
CB1SPDTCOMP Dead Time Start Enable (22)
CB Autoclose (32)
Pr
epare Reclaim Initiation (34)
CB Healthy and System Check
Timers (39)
CB single-phase dead time is complete
CBARCancel Reclaim Time (35) AR In Progress (16) Cancel CB Autoreclose
P54A/B/C/E Chapter 7 - Autoreclose
P54xMED-TM-EN-1 139
