X12:
PLC outputs
X13, X14, X15:
Key connections
 X13: Terminal strip for the '"machine control voltage ON" key
 X14: Terminal strip for the "NC stop" key
 X15: Terminal strip for the "NC start" key
Terminal X12 PLC operand Meaning Signal
1 O0 NC start lamp From terminal strip X15
2 O1 NC stop lamp From terminal strip X14
3 O2 Control voltage lamp On From terminal strip X13
4 O3 Vacant Vacant output X3
5 O4 Vacant Vacant output X3
6 O5 Vacant Vacant output X3
7 O6 Vacant Vacant output X3
8 O7 Vacant Vacant output X3
90V
10 +24 V
Note
These PLC outputs are connected to the control via the D-Sub connector X3 (MC, connector
X46).

HEIDENHAIN ITNC 530 Specifications

General

Control Type	CNC
Look-ahead	Yes
Spindle control	Yes
Touch probe cycles	Yes
Operating voltage	24 V DC
Programming	Conversational and DIN/ISO programming
Interpolation	Linear, Circular, Helical
Data Interface	Ethernet, USB, RS-232
Memory	1 GB
Programming Language	HEIDENHAIN plain language
Operating Modes	Manual, Automatic, MDA
Software Options	Various software options available
