30 – 604 HEIDENHAIN Service Manual iTNC 530
MP3143 Mounting configuration of the spindle position encoder
Input: 0: Position encoder directly on the first spindle
1: Position encoder via transmission (ratio in MP3450.x and MP3451.x); X30 pin 1:
reference pulse
2: Position encoder via transmission (ratio in MP3450 and MP3451); X30 pin 1:
reference pulse release
3: Same as input value 1, except that the second reference pulse is evaluated.
PLC
RUN
MP3210.0-7 Analog nominal spindle voltage at rated speed for the gear ranges 1 to 8
Input: 0 to 100.000 [V]
Digital spindle motor revolutions at rated speed for the gear ranges 1 to 8
Input: 0 to 100,000 [1000 rpm]
PLC
RUN
MP3240.1 Analog spindle: Minimum nominal value voltage
Input: 0 to 9.999 [V]
Digital spindle: Minimum motor speed
Input: 0 to 100,000 [1000 rpm]
PLC
RUN
MP3240.2 Analog spindle: Spindle jog voltage for gear shifting (M4009/M4010)
Input: 0 to 9.999 [V]
Digital spindle: Motor speed for gear shifting (M4009/M4010)
Input: 0 to 100,000 [1000 rpm]
MP3310 Limitation for spindle speed override
Input: 0 to 150 [%]
PLC
RUN
MP3310.0 Upper limit
MP3310.1 Lower limit
MP3350 Maximum permissible overshoot of the spindle speed in percent of the nominal spindle
speed
Input: 0 to 100 [%]
340 490-03
MP3351 Entry of an absolute value for the permissible overshoot of the spindle speed
Input: 0.001 to 100000.000 [U/min]
0 = Monitoring off
340 490-03
MP3411.0-7 Ramp gradient of the spindle with M03 and M04 for gear ranges 1 to 8
Input: Analog axes: 0 to 1.999 [V/ms]
Digital axes: 0 to 1.999 [(1000 rpm)/ms]
PLC
RUN
MP3412 Multiplication factor for MP3411.x
Input: 0.000 to 1.999
PLC
RUN
MP3412.0 With M05
MP3412.1 With oriented spindle stop
MP3412.2 With tapping with floating tap holder
MP3412.3 With rigid tapping
MP3415 Overshoot behavior of the spindle with M03, M04 and M05
Input: 0 to 1000 [ms]
PLC
RUN
MP3415.0 With M03, M04 and M05
MP3415.1 For oriented spindle stop
MP3415.2 With tapping
MP3415.3 With rigid tapping
MP3420 Spindle positioning window
Input: 0 to 360.0000 [°]
PLC
RUN
MP3430 Deviation of the reference mark from the desired position (spindle preset)
Input: 0 to 360 [°]
PLC
RUN
MP Function and input SW version
and
behavior

HEIDENHAIN ITNC 530 Specifications

General

Control Type	CNC
Look-ahead	Yes
Spindle control	Yes
Touch probe cycles	Yes
Operating voltage	24 V DC
Programming	Conversational and DIN/ISO programming
Interpolation	Linear, Circular, Helical
Data Interface	Ethernet, USB, RS-232
Memory	1 GB
Programming Language	HEIDENHAIN plain language
Operating Modes	Manual, Automatic, MDA
Software Options	Various software options available
