OPERATOR'S STATION
1-58
Adjusting the Seat
Seat Fore-aft Adjustment
Releasetheseatlockbypullinginadjusterbar(1)
horizontally.Movetheseatbackwardandforward.Seat
fore-aftisadjustablein120mmrangein6steps,20mmper
step.
Tool Box
ZX30U-5N, 35U-5N
Thetoolboxislocatedattherightsideincover(2).
ZX50U-5N, 60USB-5N
Thetoolboxislocatedattherightsideincover(2)andthe
left side of cab.
Seat Back Box
Pocket(4)islocatedatthebacksideoftheseat.
Puttheoperator’smanualinside.
1
ToolBox
2
MADB-01-071
4
MADG-01-083
MADG-01-131
ZX50U-5N,60USB-5N
