Hitachi ZAXIS 30U-5N User Manual

OPERATING THE MACHINE
5-27
Shackle Bracket Usage
Ashacklebracketisprovidedonthetrackframetotowlight
weight objects as specified below.
IMPORTANT: Be sure to conform to the restrictions and
precautions stated below when towing a light weight
object using the shackle bracket provided on the track
frame. The track frame and/or the shackle bracket may
be damaged otherwise.
 Themaximumdrawbarpull.
Model MaximumDrawbarPull
ZX30U-5N 9300N(950kgf)
ZX35U-5N 9300N(950kgf)
ZX50U-5N 13200N(1350kgf)
ZX60USB-5N 17200N(1750kgf)
 Besuretouseashackle.
 Keep the tow line horizontal, straight, and parallel to the
tracks.
 Selecttheslowtravelmode.Slowlydrivethemachine
when towing.
WireRopes
M1NE-04-002
Shacklebracketfortowing
lightweight objects
