Hitachi ZAXIS 30U-5N User Manual

OPERATOR'S STATION
1-17
Alarm List Display
IMPORTANT: Warning code (15) that has "ENG" at the
code top indicates the engine failure. If it is displayed,
immediately consult your authorized Hitachi dealer.
f
NOTE:
Alarm list (13) will be displayed on MENU screen (12) only
when an alarm occurs.
Alarm list (13) contains only currently generated alarms.
1. Pushmenuswitch(7)onbasicscreen(8)todisplay
MENUscreen(12).
2. SelectAlarmList(13)onMENUscreen(12).Pushset
switch (14).
3. Thecurrentlygeneratedalarmisdisplayed.Thealarm
markisdisplayedontheleftside,andthewarningcode
isdisplayednexttothealarmmark.
 Referto"ContentsofAlarms"onthenextpagefor
contents of the warning codes.
ZX30U-5N,35U-5N ZX50U-5N,60USB-5N
12 12
13 13
15
14 14
8
7
MADH-01-021
MADG-01-093MADG-01-092
MADG-01-094
