PIPING FOR BREAKER AND CRUSHER
OPTIONAL ATTACHMENT
Piping for Breaker and Crusher (Optional)
Operational procedures for selection valve and Plug,
Flat Face Coupling
A:SelectionValve
Removearubbercapandchangetheattachment.
B:Plug
ZX30U-5N YearofManufacturing:ToNov.2018
PartNo.List
PipeNominalSize O-Ring Plug
1-3/16-12UN 4187308 4209823
ZX30U-5N,35U-5N ZX60USB-5NZX50U-5N
MADB-13-003 MADB-13-004 MADC-12-003
MADG-13-007
A
MADG-13-008
Pipe O-Ring Plug
B
MABC-13-003
Whentheattachmentisdisconnected
