OPERATING THE MACHINE
5-22
ZX30U-5N: 600mm(24in)
ZX35U-5N: 600mm(24in)
ZX50U-5N: 650mm(26in)
ZX60USB-5N: 700mm(28in)
MZX5-13-015
MZX5-13-016
MZX5-13-018
Avoid Hitting Blade With Bucket
Whenrollinginthearminatravelortransportationposition,
becarefulnottohitthebladewiththebucket.
Avoid Colliding Blade Against Rocks
Donotattempttoallowthebladetocollidewithrocks.
Prematuredamagetothebladeandthebladecylindersmay
result.
Avoid Colliding Boom Cylinder With Track
Whendiggingdeeplywiththefrontattachmentpositioned
at an angle, as illustrated, the boom cylinder may accidentally
collidewiththetrack,causingdamage.Takeextracareto
prevent this from happening.
Precautions for Installing Wide Bucket or Special
Type Bucket
Iftheboomisfullyoffsettotheleftandraisedonthecab-
equippedmachinewithabucketwiderthanshowntothe
rightinstalled,thebucketwillcomeincontactwiththecab.Be
suretoinstallaspeciallyarrangedbucketonlyafterconsulting
your authorized dealer to prevent the cab collision with the
bucket.
