SPECIFICATIONS
12-9
Model ZX50U-5N
Specification Canopy Cab
TypeofFront-End
Attachment
- BoomSwingType,1.38m(4ft6in)Arm
BucketCapacity(Heaped) m
3
(yd
3
) 0.16(0.21)
OperatingWeight kg(lb) 4790(10560) 4920(10850)
BaseMachineWeight kg(lb) 3680(8110) 3810(8400)
Engine kW/min
-1
(PS/rpm)
YANMAR4TNV88C
27.1/2400
(36.8/2400)
A: OverallWidth mm(ft·in) 1850(6'1'')
B: OverallHeight mm(ft·in) 2530(8'4'')
C: RearEndSwingRadius mm(ft·in) 1000(3'3")
D: MinimumGround
Clearance
mm(ft·in) 340(1'1'')
E: Counterweight
Clearance
mm(ft·in) 610(2')
F: EngineCoverHeight mm(ft·in) 1590(5'3'')
G: Undercarriage Length mm(ft·in) 2500(8'2'')
H: UndercarriageWidth mm(ft·in) 2000(6'7'')
I: SprocketCentertoIdler
Center
mm(ft·in) 2000(6'7'')
J: TrackShoeWidth mm(ft·in) 400(1'4'')
GroundPressure
kPa
(kgf/cm
2
, psi)
27
(0.28,4.0)
28
(0.29, 4.1)
SwingSpeed min
-1
(rpm) 9.0 (9.0)
TravelSpeed(fast/slow) km/h(mph) 4.2/2.5(2.6/1.6)
Gradeability 30°(tanθ=0.58)
f
NOTE: The dimensions do not include the height of the shoe lug. The dimensions of the machine equipped with rubber
crawlers are shown.
Std. Specification
ZX50U-5N
A
B
D
H
J
F
E
G
I
C
MADG-12-003
