OPERATOR'S STATION
1-16
Alarm Occurrence Screen
Error Display Screen
If it occurs abnormality that can cause severe machine
damage, the basic screen changes to error display (1) and
thebuzzersoundscontinuously.Alarmmark(2),errorcode
(3)andhourmeter(4)aredisplayedonerrordisplay(1).
Whenerrordisplay(1)isshown,youcannotchangethe
screen.
In case error display (1) is shown, move the machine to the
safe place and consult your authorized Hitachi dealer.
Warning Display Screen
Incaseabnormalityoccursonthemachine,warningmark
(5)andwarningcode(6)aredisplayedonthemiddleofthe
screen.
Inthiscondition,pushmenuswitch(7)toturnoffwarning
mark(5)andreturntobasicscreen(8).Oncethewarning
markisdisplayed,itwillremainonthetopleftofscreen(9)
until the abnormality is resolved.
Tocheckthedescriptionofalarm,pushmenuswitch(7)on
basicscreen(8)todisplayalarmlist(13).
f
NOTE: Up to 3 alarm marks are displayed on the top left of
screen (9). If 4 or more alarms occur, check alarm list (13) on
menu screen (12).
The overheat alarm and the engine oil pressure alarm are
separately located on the top of the monitor. If either one
hasfailed,thealarmindicatorremainsON;thuswarning
markwillnotbedisplayedonthetopleftofscreen(9).
However,itwillbedisplayedonalarmlist(13).
ErrorDisplay
WarningDisplay
ZX30U-5N,35U-5N ZX50U-5N,60USB-5N
12 12
13 13
MADH-01-019
MADH-01-020
MADH-01-021
8
9
7
7
1
3
2
4
5
6
MADG-01-093MADG-01-092
