Chapter 2 — Set Up the Printer
PD43 and PD43c Commercial Printer User Manual 31
Load Media for Tear-Off Printing
Depending on the type of media you use, you may also need to install
a printer accessory. If you need to print on tag media, Intermec
recommends installing the optional thick media springs before
printing. If you need to print on linerless media, you must install the
linerless media roller accessory before printing.
1 Open the top of the printer first and then open the media
compartment door.
Note: Feed adjust values for simulator command languages like ESim,
ZSim, and DSim are preset.
Recommended Feed Adjust Values for Tear-Off Printing
Printer Setting 203 dpi 300 dpi Distance
PD43 Start Adjust -133 -197 -16.7 mm (0.66 in)
Stop Adjust 0 0 0 mm (0 in)
PD43c Start Adjust -133 -197 -16.7 mm (0.66 in)
Stop Adjust 0 0 0 mm (0 in)
Note: When removing printed labels on linerless media, tear the label
up towards the top of the printer to prevent media jams.
