Chapter 2 — Set Up the Printer
PD43 and PD43c Commercial Printer User Manual 35
11 Press the Print button to advance the media.
If you have not yet calibrated the media feed, press and hold the
Print button. The printer feeds one label and then prints a media
configuration test label. If you are using small labels, the printer
may feed more than one before printing the configuration label.
12 Configure the feed adjust settings.
About Cut-Off Printing
In cut-off printing, each label is automatically cut from the media roll
immediately after the label is printed. You can print on non-adhesive,
continuous label stock. You can also use self-adhesive labels with a
liner, but you must cut only the liner.
The cutter module includes the top of form sensor. You can also install
the optional cutter tray accessory, which holds up to 20 labels or
tickets.
After you load media, you need to configure the cutter and the feed
adjust settings. You may need to adjust the recommended values
slightly depending on your media type, supply method, and roll sizes,
or because of individual differences between printers.
Caution: You must not use the cutter to cut through any kind of
adhesive, or other soft material, that may stick to the cutting parts
and render the cutter inoperable or even damage the electric
motor.
Recommended Feed Adjust Values for Cut-Off Printing
Printer Setting 203 dpi 300 dpi Distance
PD43 Start Adjust -280 -414 -35.1 mm (-1.38 in)
Stop Adjust 147 217 18.4 mm (0.72 in)
PD43c Start Adjust -280 -414 -35.1 mm (-1.38 in)
Stop Adjust 147 217 18.4 mm (0.72 in)
