224
Item Description
Source Select the operators and, enter the source port numbers and
destination port numbers as required.
These items are available only when you select
6 TCP
or
17
UDP
from the
Protocol
list.
Different operators have different configuration requirements
for the port number fields:
• Not Check—The following port number fields cannot be
configured.
• Range—The following port number fields must be
configured to define a port range.
• Other values—The first port number field must be
configured and the second must not.
Destination
Precedence
Filter
DSCP Specify the DSCP priority.
TOS Specify the ToS preference.
Precedence Specify the IP precedence.
Time Range
Select the time range during which the rule takes effect.
Configuring a rule for an Ethernet frame header
ACL
Select Advanced > QoS Setup > ACL IPv4 from the navigation tree and then select the Link
Config tab to enter the rule configuration page for an Ethernet frame header IPv4 ACL.
