Huawei FusionModule800 Installation Guide

FusionModule800 Smart Small Data Center
Installation Guide (Six Fans)
4 Cable Routing
Issue 10 (2019-12-20)
Copyright © Huawei Technologies Co., Ltd.
209
4.5.1.2 (Optional) Connecting Signal Cables to the Converged Cabinet
Prerequisites
The ATS PDU has been configured.
Context
If the Converged Cabinet is configured with an ATS PDU, connect the diesel generator (DG)
and fire extinguishing signal cables to the XT6 terminal block. Table 4-2 describes the cable
connections.
Table 4-2 Cable connection description
Cable Connecting Position on the ATS
PDU
Cable Connecting Position on the
Device
XT6-1
Fire Protection-Fire
XT6-2
Fire Protection-COM
XT6-3
Generator-START
XT6-4
Generator-COM
XT6-5
Generator-STOP
Procedure
Step 1 Connect the DG and fire extinguishing signal cables to the XT6 terminal block, as shown in
Figure 4-24. Table 4-2 describes the cable connections.
