Huawei FusionModule800 Installation Guide

FusionModule800 Smart Small Data Center
Installation Guide (Six Fans)
2 Installation Preparations
Issue 10 (2019-12-20)
Copyright © Huawei Technologies Co., Ltd.
17
Name, Specifications, and Appearance
temperatures higher than 85°C and the following requirements are met:

Applicable to all pipe materials

Anaerobic metal pipe thread sealant with PTEF as the padding

Maximum gap: 0.5 mm

Pressure resistance: above 1.6 MPa

Compliant with the industry standard JB∕T7311-2008 Technical Specification for the
Application of Anaerobic Glue in Engineering Machinery
2.2 Checking the Installation Environment
Ensure that the installation environment meets the requirements before installation.
Table 2-3 Installation environment checklist
Check Item
Specifications
Check Result
Bearing capacity

Standard live load of the main
equipment room: 8-12 kN/m
2
(If the
battery cabinet is placed inside the
module, use the standard live load of the
main equipment room as a reference.)

Suspended load of the main equipment
room: 1.2 kN/m
2

Standard live load of the battery room:
16 kN/m
2
□ Passed □ Failed
Levelness
Allowed deviation: 3/2000 mm
□ Passed □ Failed
Equipment room
height
≥ 2.6 m
□ Passed □ Failed
Equipment room
area
8-30 m
2
□ Passed □ Failed
Door size
Height > 2.2 m; width > 0.9 m
□ Passed □ Failed
Elevator
Elevator bearing capacity > 1.5 t
Elevator internal size: height > 2.4 m,
depth > 1.4 m
Elevator door size: height > 2.2 m; width >
0.9 m
□ Passed □ Failed
Power supply
380 V AC/400 V AC/415 V AC, 3 Ph, 50
Hz/60 Hz
□ Passed □ Failed
Lighting

Equipment room: 500 lx

Monitoring center: 500 lx
□ Passed □ Failed
