FusionModule800 Smart Small Data Center
Installation Guide (Six Fans)
Copyright © Huawei Technologies Co., Ltd.
Figure 3-19 Installing an aisle side sealing plate on an end cabinet
Step 5 Install an aisle side sealing plate on the other end cabinet in the same manner.
----End
3.4 Adjusting the Positions of Cabinet Side Panels
3.4.1 Adjusting the Positions of IT Cabinet Side Panels
Prerequisites
An IT cabinet is configured.
Context
Before installing an IT cabinet, adjust the side panel position and ensure that side panel
is installed on the cabinet side towards the aisle exterior.
Install two side panels for each end cabinet, one in the upper part and the other in the
lower part.
