Maintenance Guide

5-32

2) Replacement of WAIT1 sensor and C-CUT sensor

Replace the fibers inserted in the amplifier of C-OUT and that of WAIT1.

(Emission and reception of light)

Amplifier of WAIT1

Amplifier of C-OUT
