JUKI RS-1 User Manual

Maintenance Guide
11-1
11 Switch Related
DANGER
To prevent any trouble caused by accidental machine start,
always shut-down the power before starting the maintenance
and adjustment work.
11-1 Replacing the Push-Button Switch
Replacing the Push-Button Switch
① Coplanarity laser power switch
(Provided when the optional coplanarity is mounted.)
② Coplanarity laser ON lamp
(Provided when the optional coplanarity is mounted.)
③ Start/origin switch
④ Stop switch
⑤ Front/rear operation change-over switch
(Provided when the rear operation panel is mounted.)
⑥ Key switch
Front
Rear
3
5
4
1
3
5
4
2
6
