Maintenance Guide
17-4
17-2 Changing the IP Address of the Coplanarity CPU
When setting the IP address of the coplanarity CPU, make the setting while referring to the cautions
on the TCP/IP setting in section 13-2-2, Setting Up the Network (Setup is required when
communicating with the JaNets.).
17-2-1 Required Parts
① Mouse (USB)
② Keyboard (USB)
* Generally available PS2 connection mouse and keyboard, or the keyboard with track ball
(40132158) is separately required.
17-2-2 Setting Preparations
1) Make sure that the mounter power is turned OFF, and then connect the mouse and
keyboard you have prepared to the coplanarity CPU (40163856) at the lower left position on
the front.
2) Detach the rear cover. Change the change-over switch on the coplanarity monitor change
board (40097434) in the direction indicated by an arrow.
To Next Page
