JUKI RS-1 User Manual

Maintenance Guide
18-2
Rear side
CVS unit
CVS base
Washer assembled hexagon socket cap
bolt M6, L=16
* Carefully check the assembly position.
Cable connection
(2 cables)
CONTACT SUB UNIT
CVS cover
Flat head screw
M3, L=5
