JUNOS Internet Software Network Operations Guide: Hardware
304 ! Understanding the Control Board
T320 Router Control Board
Figure 125 shows the T320 router Control Board component of the host subsystem.
Figure 125: T320 Router Control Board Component
T640 Routing Node Control Board
Figure 126 shows the T320 router Control Board component of the host subsystem.
Figure 126: T640 Routing Node Control Board Component
2018
Extractor clip
Ethernet
port
Extractor clip
Online/offline
button
LEDs
1520
Extractor clip
Extractor clip
Online/offline
button
Ethernet
port
LEDs
