KTM 2013 690 SMC R EU User Manual

21 TECHNICAL DATA 178
21.8 Fork
Fork part number 14.18.7L.12
Fork WP Suspension Up Side Down 4860 ROMA
Compression damping
Comfort 25 clicks
Standard 20 clicks
Sport 15 clicks
Full load capacity 15 clicks
Rebound damping
Comfort 20 clicks
Standard 15 clicks
Sport 10 clicks
Full load capacity 10 clicks
Spring length with preload spacer(s) 462 mm (18.19 in)
Spring rate
Medium (standard) 5.3 N/mm (30.3 lb/in)
Hard 5.6 N/mm (32 lb/in)
Air chamber length 100±20 mm (3.94±0.79 in)
Fork length 900 mm (35.43 in)
Fork oil per fork leg 644 ml (21.77 fl. oz.) Fork oil (SAE 4) (48601166S1) ( p. 207)
21.9 Shock absorber
Shock absorber part number 15.18.7L.12
Shock absorber WP Suspension 4618 with Pro‑Lever deflector
Compression damping, high-speed
Comfort 2 turns
Standard 1.5 turns
Sport 1 turn
Full payload 1 turn
Compression damping, low-speed
Comfort 25 clicks
Standard 20 clicks
Sport 15 clicks
Full load capacity 15 clicks
Rebound damping
Comfort 20 clicks
Standard 15 clicks
Sport 10 clicks
Full payload 10 clicks
Spring preload 20 mm (0.79 in)
Spring rate
Medium (standard) 80 N/mm (457 lb/in)
Hard 85 N/mm (485 lb/in)
Spring length 220 mm (8.66 in)
Gas pressure 10 bar (145 psi)
Static sag 20… 25 mm (0.79… 0.98 in)
Riding sag 70… 80 mm (2.76… 3.15 in)
Fitted length 395 mm (15.55 in)
Shock absorber fluid Shock absorber oil (SAE 2.5) (50180342S1) ( p. 207)
