21.10 Chassis tightening torques

Screw, chain guard EJOT 2 Nm (1.5 lbf ft) –

Screw, combination instrument EJOT 1 Nm (0.7 lbf ft) –

Screw, license plate holder, bottom EJOT 3 Nm (2.2 lbf ft) –

Screw, side stand switch EJOT 2 Nm (1.5 lbf ft) –

Screw, SLS valve EJOT 2 Nm (1.5 lbf ft) –

Fitting, side stand switch M4 2 Nm (1.5 lbf ft) –

Screw, fuel hose clamp on fuel tank M4 2 Nm (1.5 lbf ft) –

Screw, wheel speed sensor M4 1 Nm (0.7 lbf ft)

Loctite

243™

Spoke nipple, front wheel M4.5 3… 6 Nm (2.2… 4.4 lbf ft) –

Spoke nipple, rear wheel M4.5 3… 6 Nm (2.2… 4.4 lbf ft) –

Bolt, foot brake lever stub M5 6 Nm (4.4 lbf ft)

Loctite

243™

Remaining screws, chassis M5 4 Nm (3 lbf ft) –

Screw, brake line holder on swingarm M5 4 Nm (3 lbf ft) –

Screw, cable on starter motor M5 3 Nm (2.2 lbf ft) –

Screw, electrical holder M5 3 Nm (2.2 lbf ft) –

Screw, exhaust heat shield M5 8 Nm (5.9 lbf ft)

Loctite

243™

Screw, fuel level sensor M5 3 Nm (2.2 lbf ft) –

Screw, fuel pump M5 4 Nm (3 lbf ft) –

Screw, fuel tank closure flange M5 2.5 Nm (1.84 lbf ft) –

Screw, headlight mask M5 5 Nm (3.7 lbf ft) –

Screw, pressure regulator M5 4 Nm (3 lbf ft) –

Remaining nuts, chassis M6 10 Nm (7.4 lbf ft) –

Remaining screws on fuel tank M6 5 Nm (3.7 lbf ft) –

Remaining screws, chassis M6 10 Nm (7.4 lbf ft) –

Screw connection, foot brake cylinder M6 10 Nm (7.4 lbf ft) –

Screw, air filter box top M6 2 Nm (1.5 lbf ft) –

Screw, ball joint of push rod on foot

brake cylinder

M6 10 Nm (7.4 lbf ft)

Loctite

243™

Screw, brake fluid reservoir of rear

brake

M6 5 Nm (3.7 lbf ft) –

Screw, chain guard M6 2 Nm (1.5 lbf ft)

Loctite

243™

Screw, chain guide M6 8 Nm (5.9 lbf ft) –

Screw, chain sliding guard M6 8 Nm (5.9 lbf ft)

Loctite

243™

Screw, front brake disc M6 14 Nm (10.3 lbf ft)

Loctite

243™

Screw, ignition lock M6 10 Nm (7.4 lbf ft)

Loctite

243™

Screw, lower radiator bracket M6 8 Nm (5.9 lbf ft) –

Screw, magnetic holder on side stand M6 6 Nm (4.4 lbf ft)

Loctite

243™

Screw, radiator guard M6 8 Nm (5.9 lbf ft) –

Screw, rear brake disc M6 14 Nm (10.3 lbf ft)

Loctite

243™

Screw, seat lock M6 5 Nm (3.7 lbf ft) –

Screw, side cover M6 5 Nm (3.7 lbf ft) –

Screw, upper radiator bracket M6 10 Nm (7.4 lbf ft) –

Screw, voltage regulator M6 8 Nm (5.9 lbf ft) –

Nut, manifold on cylinder head M8 20 Nm (14.8 lbf ft) Copper paste

Nut, rear sprocket screw M8 35 Nm (25.8 lbf ft) Loctite

2701

Remaining nuts, chassis M8 25 Nm (18.4 lbf ft) –

Remaining screws, chassis M8 25 Nm (18.4 lbf ft) –

Screw, bottom triple clamp M8 12 Nm (8.9 lbf ft) –

Screw, chain sliding piece M8 15 Nm (11.1 lbf ft) –

Screw, connection lever on frame M8 30 Nm (22.1 lbf ft)

Loctite

243™

Screw, foot brake lever M8 25 Nm (18.4 lbf ft)

Loctite

243™
