27 AUXILIARY SUBSTANCES 208

Chain cleaner

Guideline

– KTM recommends Motorex

products.

Supplier

Motorex

– Chain Clean

Chain lube for road use

Guideline

– KTM recommends Motorex

products.

Supplier

Motorex

– Chainlube Road

Cleaning and preserving materials for metal, rubber and plastic

Guideline

– KTM recommends Motorex

products.

Supplier

Motorex

– Protect & Shine

Fuel additive

Guideline

– KTM recommends Motorex

products.

Supplier

Motorex

– Fuel Stabilizer

High-luster polish for paint

Guideline

– KTM recommends Motorex

products.

Supplier

Motorex

– Moto Polish

Long-life grease

Guideline

– KTM recommends Motorex

products.

Supplier

Motorex

– Bike Grease 2000

Lubricant (T511)

Guideline

– KTM recommends Lubcon

products.

Supplier

Lubcon

– Turmsilon

GTI 300 P

Lubricant (T158)

Guideline

– KTM recommends Lubcon

products.

Supplier

Lubcon

– Turmogrease

PP 300
