• * Manufacturer's estimate
The company reserves the right to change the specifications without notice.
9Y1211156INI0001US0
Model B2301 B2601
PTO power *1 17.5 kW (13.0 HP) 19.5 kW (14.5 HP)
Engine
Maker KUBOTA
Model D1005-E4-D32 D1105-E4-D32
Type E-TVCS. Liquid-cooled, 3-cylinder diesel
Number of cylinders 3
Bore and stroke 76 × 73.6 mm (3.0 × 2.9 in.) 78 × 78.4 mm (3.1 × 3.1 in.)
Total displacement 1001 cc (61.1 cu.in.) 1123 cc (68.5 cu.in.)
Engine gross power *1 22 kW (16.4 HP) 25.5 kW (19.0 HP)
Rated revolution 2800 min
-1
(rpm)
Low idling revolution 1000 to 1100 min
-1
(rpm)
Maximum torque 60 N·m (6.1 kgf·m, 44 lbf·ft) 71 N·m (7.2 kgf·m, 52 lbf·ft)
Battery 12 V, RC: 80 min, CCD: 430 A
Capacities
Fuel tank 23 L (6.1 U.S.gals, 5.1 Imp.gals)
Engine crankcase (with filter) 3.1 L (3.3 U.S.qts, 2.7 Imp.qts)
Engine coolant 3.8 L (4.0 U.S.qts, 3.3 Imp.qts)
Transmission case 15 L (4.0 U.S.gals, 3.3 Imp.gals)
Dimensions
Overall length (without 3P) 2380 mm (93.7 in.) 2410 mm (94.9 in.)
Overall width (min. tread) 1150 mm (45.3 in.) 1245 mm (49.0 in.)
Overall height 2130 mm (83.9 in.) 2160 mm (85.0 in.)
Wheel base 1560 mm (61.4 in.)
Minimum ground clearance 305 mm (12.0 in.) 325 mm (12.8 in.)
Tread
Front 800 mm (31.5 in.) 815 mm (32.1 in.)
Rear 900 mm (35.5 in.) 950 mm (37.4 in.)
Weight 710 kg (1566 lbs) 740 kg (1632 lbs)
Clutch Not applicable
Traveling
system
Tires
Front 6-12 7-12
Rear 9.5-16 11.2-16
Steering Hydraulic type power steering
Transmission HST (3 range)
Brake Wet disk type
Minimum turning radius (with
brake)
2.1 m (6.9 feet)
Hydraulic unit
Hydraulic control system Position Control Valve
Pump capacity 31.4 L/min (8.3 gals/min)
3-point hitch SAE Category 1
Max. lift force
At lift points 820 kg (1808 lbs)
24 in. behind
lift point
640 kg (1411 lbs)
PTO
Rear-PTO SAE 1-3/8, 6 splines
PTO / Engine
speed
540 min
-1
(rpm) / 2768 min
-1
(rpm)
Mid-PTO USA No.5 (KUBOTA 10-tooth) involute spline
PTO / Engine
speed
2500 min
-1
(rpm) / 2753 min
-1
(rpm)
