Kubota B2301 Workshop Manual

GENERAL
B2301, B2601, WSM
G-48
(2) Rear Wheels
Rear Wheels
Rear tread width can not be adjusted.
IMPORTANT
• Always attach tires as shown in the drawings.
• If not attached as illustrated, transmission parts may be
damaged.
• When re-fitting or adjusting a wheel, tighten the bolts to the
following torques then recheck after driving the tractor
200 m (200 yards) and 10 times of shuttle movement by 5 m
(5 yards), and thereafter according to service interval. (See
"MAINTENANCE" section.)
WARNING
To avoid personal injury or death:
• Before jacking up the tractor, park it on a firm and level
ground and chock the front wheels.
• Fix the front axle to keep it from swinging.
• Select jacks that withstand the machine weight and set
them up as shown below.
[A] Wheels with beveled or tapered holes
Use the tapered side of lug nut.
[B] Wheels without beveled or tapered holes
Use the flat side of lug nut. Make sure to apply the spring
washer.
9Y1211156GEG0069US0
(1) Jack Point
(2) Lug Nut
(3) Spring Washer
KiSC issued 11, 2014 A

Kubota B2301 Specifications

General

Engine Type	Diesel
Transmission Type	Hydrostatic
Type	Compact Utility Tractor
Drive	4WD
3-Point Hitch Category	Category I
Fuel Capacity	6.1 gallons
Hydraulic System Capacity	3.7 gallons
