Kubota B2301 Workshop Manual

ELECTRICAL SYSTEM
B2301, B2601, WSM
8-S1
1. TROUBLESHOOTING
FUSE AND WIRING
BATTERY
STARTING SYSTEM
Symptom
Probable Cause and
Checking Procedure
Solution
Reference
Page
All Electrical
Equipment Do Not
Operate
1. Battery discharged or
damaged
Check or recharge battery 8-S10
2. Battery positive cable
disconnected or
improperly connected
Repair or replace battery positive cable 8-S10
3. Battery negative cable
disconnected or
improperly connected
Repair or replace negative cable 8-S10
4. Slow blow fuse blown Repair main harness 8-M1
Fuse Blown
Frequently
1. Short-circuited Repair or replace fuse G-34
Symptom
Probable Cause and
Checking Procedure
Solution
Reference
Page
Battery Discharges
Too Quickly
1. Battery damaged Recharge or replace battery 8-S11
2. Dynamo damaged Repair or replace dynamo 8-S17
3. Wiring harness
disconnected or
improperly connected
Repair or replace connector and wire
harness
8-M1
4. Cooling fan belt slipping Adjust fan belt 1-S25
Symptom
Probable Cause and
Checking Procedure
Solution
Reference
Page
Starter Motor Does
Not Operate
1. Battery discharged or
damaged
Recharge or replace battery 8-S11
2. Slow blow fuse blown Replace main harness or other 8-M1
3. Safety switch improperly
adjusted or damaged
Repair or replace safety switch 8-S14
4. Wiring harness
disconnected or
improperly connected
Repair or replace connector and wire
harness
8-M1
5. Engine stop solenoid relay
damaged
Replace engine stop solenoid relay 8-S12
6. Starter motor damaged Solution order
1. Check starter motor
8-S15
2. Replace starter motor 8-S15
7. Key switch damaged Check or replace key switch 8-S13
KiSC issued 11, 2014 A

Kubota B2301 Specifications

General

Engine Type	Diesel
Transmission Type	Hydrostatic
Type	Compact Utility Tractor
Drive	4WD
3-Point Hitch Category	Category I
Fuel Capacity	6.1 gallons
Hydraulic System Capacity	3.7 gallons
