Kubota B2301 Workshop Manual

FRONT AXLE
B2301, B2601, WSM
5-S3
3. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(For general use screws, bolts and nuts: Refer to "5. TIGHTENING TORQUES" on page G-11.)
9Y1211156FAS0003US0
Item N·m kgf·m lbf·ft
Front wheel mounting bolt and nut 77.0 to 90.0 7.9 to 9.2 57.0 to 67.0
Delivery hose retaining nut 24 to 28 2.5 to 2.9 17.7 to 20.7
Front axle holder mounting bolt 200 to 230 20.4 to 23.5 147.5 to 169.6
Tie-rod slotted nut 18 to 35 1.8 to 3.5 14 to 25
Tie-rod joint 74 to 84 7.5 to 8.6 54.4 to 61.9
Bevel gear case mounting screw 77.5 to 90.1 7.9 to 9.2 57.1 to 66.5
Axle flange mounting bolt 48.1 to 55.9 4.9 to 5.7 35.5 to 41.2
KiSC issued 11, 2014 A

Kubota B2301 Specifications

General

Engine Type	Diesel
Transmission Type	Hydrostatic
Type	Compact Utility Tractor
Drive	4WD
3-Point Hitch Category	Category I
Fuel Capacity	6.1 gallons
Hydraulic System Capacity	3.7 gallons
