Kubota B2301 Workshop Manual

ELECTRICAL SYSTEM
B2301, B2601, WSM
8-S8
2. SERVICING SPECIFICATIONS
STARTER
9Y1211156ELS0002US0
Item Factory Specification Allowable Limit
Battery Voltage
Potential
Difference
More than 12 V
Less than 0.1 V
–
–
Glow Plug Resistance Approx. 0.9 Ω –
Coolant Temperature Sensor Resistance
at 130 °C (266 °F)
at 105 °C (221 °F)
at 80 °C (176 °F)
at 50 °C (122 °F)
Approx. 12.2 Ω
Approx. 23.6 Ω
Approx. 51.9 Ω
Approx. 153.9 Ω
–
–
–
–
Fuel Sensor Resistance
Float at
upper-most
position
Float at lower-most
position
1 to 5 Ω
103 to 117 Ω
–
–
Item Factory Specification Allowable Limit
Commutator O.D.
Difference of
O.D.'s
28.0 mm
1.102 in.
Less than
0.02 mm
0.0008 in.
27.0 mm
1.063 in.
0.05 mm
0.0020 in.
Mica Undercut 0.60 mm
0.0236 in.
0.20 mm
0.0079 in.
Brush Length 14 mm
0.551 in.
9.0 mm
0.354 in.
Brush Holder to Holder Support Resistance Infinity –
KiSC issued 11, 2014 A

Kubota B2301 Specifications

General

Engine Type	Diesel
Transmission Type	Hydrostatic
Type	Compact Utility Tractor
Drive	4WD
3-Point Hitch Category	Category I
Fuel Capacity	6.1 gallons
Hydraulic System Capacity	3.7 gallons
