Panasonic KX-NS500 Features Guide

2.5.5.2 Line Preference—Outgoing
Description
Through personal programming (Preferred Line Assignment-Outgoing), PT users can select the outgoing line
they prefer to originate calls on when going off-hook, from the following line preferences:
Line Preference Description
ICM/PDN When an extension user goes off-hook, an extension line is selected
automatically. If the extension is a PDN extension, the first available
Primary Directory number (PDN) button is selected automatically.
(® 2.9.1 Primary Directory Number (PDN)/Secondary Directory
Number (SDN) Extension
)
Idle Line When an extension user goes off-hook, an idle trunk is selected
automatically from the assigned trunk groups.
No Line When an extension user goes off-hook, no line is selected. The
extension user must select the desired line to make a call.
Prime Line When an extension user goes off-hook, the preset line is selected
automatically. A prime line can be selected from the Line Access
buttons: S-CO, G-CO, L-CO, ICD Group.
Conditions
• Line Preference Override
A
user can override the preset Line Preference temporarily by pressing the desired Line Access button or
Memory Dialling button (e.g., One-touch Dialling) before going off-hook.
• To select Idle Line Preference, the trunk groups available to the extension should be programmed on a
COS basis. Also trunk groups available for Idle Line Access should be assigned.
PC Programming Manual References
10.7.2 PBX Configuration—[2-7-2] System—Class of Service—External Call Block
11.1.2 PBX Configuration—[3-1-2] Group—Trunk Group—Local Access Priority
12.1.1 PBX Configuration—[4-1-1] Extension—Wired Extension—Extension Settings—Option 4—
Outgoing
Preferred Line
12.2.1
PBX Configuration—[4-2-1] Extension—Portable Station—Extension Settings—Option 4—
Outgoing
Preferred Line
PT Programming Manual References
[103] Idle Line Access (Local Access)
[500] Trunk Group Number
User Manual References
3.1.2 Settings on the Programming Mode
116 Feature Guide
2.5.5 Seizing a Line Features

Panasonic KX-NS500 Specifications

General

Analog Extensions	Up to 64
VoIP Support	Yes
System Type	Hybrid IP-PBX
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0°C to 40°C
Humidity	10% to 90% (non-condensing)
Maximum Extensions	288
IP Extensions	128
VoIP Channels	64
SIP Trunks	64
Networking	Yes, supports networking
Built-in Applications	Call Center
Expandability	Yes, via expansion cards and cabinets
Supported Protocols	SIP, H.323, MGCP
Dimensions	430 x 88 x 367 mm
