Panasonic KX-NS500 Features Guide

2.22 Administrative Information Features
2.22.1 Record Log Features
2.22.1.1 Station Message Detail Recording (SMDR)
Description
Automatically records detailed information for each extension.
1. SMDR Output Port
The following output methods can be selected through system programming:
® 19.1 PBX Configuration—[11-1] Maintenance
—Main—SMDR—
SMDR Format—Port
Output Method Description
Telnet compatible terminal emulator SMDR information is sent to a Telnet compatible terminal
emulator via LAN.
2. SMDR Output Data
The following data will be recorded and sent to the SMDR output port:
a. Trunk call information (incoming/outgoing)
b. Intercom call information (outgoing)
c. Log-in/Log
-out information
d. PBX error log (® 5.6.4 Local Alarm Information)
e. Hospitality feature information (® 2.23.1 Hospitality Features—SUMMARY)
f. Printing Message information (® 2.22.2 Printing Message)
Memory for SMDR: A specified number of call records can be stored in the PBX. If more calls are originated
or received, the oldest record is overwritten by the newest one.
3. SMDR Format Type and Contents
The following three types of output format can be selected through system programming:
260 Feature Guide
2.22.1 Record Log Features

Panasonic KX-NS500 Specifications

General

Analog Extensions	Up to 64
VoIP Support	Yes
System Type	Hybrid IP-PBX
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0°C to 40°C
Humidity	10% to 90% (non-condensing)
Maximum Extensions	288
IP Extensions	128
VoIP Channels	64
SIP Trunks	64
Networking	Yes, supports networking
Built-in Applications	Call Center
Expandability	Yes, via expansion cards and cabinets
Supported Protocols	SIP, H.323, MGCP
Dimensions	430 x 88 x 367 mm
