Panasonic KX-NS500 Features Guide

5.6.2 Power Failure Transfer
Description
When
the power supply to the PBX fails, specific SLTs are automatically connected to specific trunks (Power
Failure Connections). The PBX will switch from normal operation to the Power Failure Connections, and all
existing conversations will be disconnected.
Only the trunks handled by Power Failure Connections can be used during a power failure.
Conditions
• Only trunk calls can be made during a power failure. All other features do not work.
• The following SLT ports and LCOT ports are connected during a power failure. It is possible to allow trunk
calls that are established during a power failure to be maintained even when the power returns and the
connection is switched back to the normal configuration from the Power Failure Connection.
Main Unit Port 1 on pre-installed MCSLC16 and port 1 on pre-installed
LCOT6
Port 2 on pre-installed
MCSLC16 and port 2 on pre-installed
LCOT6
Expansion Unit Port 1-4 on pre-installed MCSLC16 and port 1-4 on LCOT6 (if
two cards are installed, the lower numbered card is used).
Installation Manual References
4.12 Power Failure Connections
552 Feature Guide
5.6.2 Power Failure Transfer

Panasonic KX-NS500 Specifications

General

Analog Extensions	Up to 64
VoIP Support	Yes
System Type	Hybrid IP-PBX
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0°C to 40°C
Humidity	10% to 90% (non-condensing)
Maximum Extensions	288
IP Extensions	128
VoIP Channels	64
SIP Trunks	64
Networking	Yes, supports networking
Built-in Applications	Call Center
Expandability	Yes, via expansion cards and cabinets
Supported Protocols	SIP, H.323, MGCP
Dimensions	430 x 88 x 367 mm
