Parker ACR Series User Manual

Parker Hannifin
Digital Input on
Aries EPL Drive
DSP-402
Object 60FD
Bit Position
Bit
Number
EPLD0 Input 0 EPLD0 3 3328
EPLD0 Input 1 EPLD0 0 3329
EPLD0 Input 2 EPLD0 1 3330
EPLD0 Input 3 EPLD0 18 3331
EPLD0 High Speed Input 4 EPLD0 2 3332
EPLD0 High Speed Input 5 EPLD0 16 3333
EPLD0 High Speed Input 6 EPLD0 17 3334
No function EPLD0 19 3335
EPLD1 Input 0 EPLD1 3 3336
EPLD1 Input 1 EPLD1 0 3337
EPLD1 Input 2 EPLD1 1 3338
EPLD1 Input 3 EPLD1 18 3339
EPLD1 High Speed Input 4 EPLD1 2 3340
EPLD1 High Speed Input 5 EPLD1 16 3341
EPLD1 High Speed Input 6 EPLD1 17 3342
No function EPLD1 19 3343
EPLD2 Input 0 EPLD2 3 3344
EPLD2 Input 1 EPLD2 0 3345
EPLD2 Input 2 EPLD2 1 3346
EPLD2 Input 3 EPLD2 18 3347
EPLD2 High Speed Input 4 EPLD2 2 3348
EPLD2 High Speed Input 5 EPLD2 16 3349
EPLD2 High Speed Input 6 EPLD2 17 3350
No function EPLD2 19 3351
EPLD3 Input 0 EPLD3 3 3352
EPLD3 Input 1 EPLD3 0 3353
EPLD3 Input 2 EPLD3 1 3354
EPLD3 Input 3 EPLD3 18 3355
EPLD3 High Speed Input 4 EPLD3 2 3356
EPLD3 High Speed Input 5 EPLD3 16 3357
EPLD3 High Speed Input 6 EPLD3 17 3358
No function EPLD3 19 3359
Table 78 P4200 (EPLD0 – EPLD3 Digital Inputs)
Appendix H ETHERNET Powerlink 177
