Ethernet Connector
The ACR90x0 controllers implement a single Ethernet network interface with
the following features:
• 10/100 Mbps (self-configuring), full-duplex capable connection
• TCP/IP version 4
• UDP protocols
Ethernet Connector Pinout
Table 33 contains the connector pinout for the Ethernet connector:
Signal Pin Wire Color
TX+ 1 White with orange
TX- 2 Orange
RX+ 3 White with green
* 4 Blue
* 5 White with blue
RX- 6 Green
* 7 White with brown
* 8 Brown
* Terminated internally: 4x75-ohm, 1000pF (2kV) to shield
Table 33 Ethernet Connector Pinout
ETHERNET Powerlink Connectors
The ACR9030 and ACR9040 controllers implement two ETHERNET
Powerlink interfaces with the following features:
• 100 Mbps, full-duplex capable connection
• ETHERNET Powerlink protocols
ETHERNET Powerlink Connector Pinout
Table 34 contains the connector pinout for the ETHERNET Powerlink
connector:
Signal Pin Wire Color
RX+ 1 White with orange
RX- 2 Orange
TX+ 3 White with green
* 4 Blue
* 5 White with blue
TX- 6 Green
* 7 White with brown
* 8 Brown
* Terminated internally: 4x75-ohm, 1000pF (2kV) to shield
Table 34
ETHERNET Powerlink Connector Pinout
60 ACR9000 Series Hardware Installation Guide
