Chapter 2 Specifications 61
USB Connector
The ACR90x0 controller implements the USB interfa
ce with the following
features:
•
USB 2.0 full-speed device, 12 Mbps
•
Self-powered— it does not draw power t
hrough the USB interface
USB Connector Pinout
The USB connector is a Series B receptacle. The
connector pin-out follows:
Signal
Pin
Wire Color (typical)
Vbus
1
Red
D-
2
White
D+
3
Green
GND
4
Black
Shield
Shell
—
Table 35 USB Connector Pinout
